Advanced 15T MRI System for Precision Diagnostics
GoldHealth Medical: Revolutionizing MRI Technology
GoldHealth Medical proudly introduces its state-of-the-art 1.5T Magnetic Resonance Imaging system, designed to deliver unparalleled imaging performance and user-friendly operation. Engineered for precision and versatility, this MRI system is tailored to meet the needs of hospitals, clinics, research institutions, and more.
Key Features
- Exceptional Optical Performance: Combines advanced technology with an intuitive design for superior imaging results.
- Ease of Use: Streamlined operational processes ensure seamless integration into any medical environment.
Technical Specifications
Magnet
- Field Strength: 1.5T
- Type: Superconducting
- Shimming: Passive, Active, and Dynamic shimming for optimal field stability
- Electromagnetic Interference Shielding: Equipped with advanced shielding technology
- Long-Term Stability: ≤0.125ppm/h
- Field Homogeneity (V-RMS):
- 50cm DSV: ≤0.75ppm
- 45cm DSV: ≤0.37ppm
- 40cm DSV: ≤0.18ppm
- 30cm DSV: ≤0.05ppm
- 20cm DSV: ≤0.015ppm
- 10cm DSV: ≤0.002ppm
- Patient Aperture: 600mm for enhanced patient comfort
Gradient
- Type: Single (Non-Resonant)
- Max. Amplitude (X-, Y-, Z-Axis): 40mT/m
- Max. Slew Rate (X-, Y-, Z-Axis): 133mT/m/ms
RF Transmit and Receive
- RF Amplifier Max. Output Power: 20kW
- Independent RF Receiving Channels: 16 Channels
- RF Receiving Coils:
- MUSIC Phased Array Head-Neck Coil: 16 Channels
- MUSIC Phased Array Spine Coil: 18 Channels
- MUSIC Phased Array Body Coil: 8 Channels
- Phased Array Knee Coil: 8 Channels
- Phased Array Shoulder Coil: 4 Channels
- Optional RF Receiving Coils:
- Phased Array Wrist Coil: 8 Channels
- Phased Array Ankle Coil: 8 Channels
- Phased Array Breast Coil: 8 Channels
- Small Flexible Coil: 4 Channels
- Large Flexible Coil: 4 Channels
Pulse Sequence and Scanning Technology
- Standard Sequences: SE, GRE, EPI, IR
- Neural System Imaging: Includes Tornado (motion artifact reduction) and SWAPP
- Abdominal Imaging: Fast dynamic enhanced volumetric scanning
- DWI, MRA, MRV, Magnetic Resonance Hydrography (MRCP): Fully supported
- Precise Quantitative Techniques:
- mLIVE (Fat Liver Quantification and Iron Liver Quantification, PDFF/R2*)
- Cartilage Quantification
- Artifact Reduction and Time-Saving Technology: Integrated for efficiency
- Optional Advanced Features:
- ASL (Impulse RF Labelling, 2D ASL & Post-Process Analysis)
- MRS (STEAM or PRESS, Single Voxel MRS, Automatic Advanced High-Order Homogenization)
GoldHealth Medical’s 1.5T MRI system is designed to redefine diagnostic imaging with its cutting-edge technology, precision engineering, and adaptability to diverse clinical applications. Elevate your facility’s capabilities with a system that combines innovation, reliability, and patient-centric design.
Common Shipping and Delivery Considerations
- Packaging:
Medical devices need secure packaging to avoid damage during transit, including shock-absorbing materials or custom foam inserts. - Compliance with Regulations:
Ensure compliance with local and international standards (e.g., FDA, CE) and shipping regulations like Good Distribution Practice (GDP). - Temperature Control:
Some devices require temperature-controlled shipping (e.g., refrigerated trucks or special packaging) to maintain product integrity. - Tracking and Documentation:
Shipments should be tracked with necessary documents like invoices, certificates, and import/export paperwork. - Lead Time:
Plan ahead for lead times, which can vary depending on the equipment size and delivery location. - Insurance: Due to the high value of medical equipment, consider insurance to protect against loss or damage during transit.
- Customs and Import Regulations: Account for customs procedures and tariffs when shipping internationally, ensuring proper documentation.
- Special Handling:
Fragile or hazardous medical devices may require special handling, with clear labeling to ensure proper care. - Delivery Method:
Choose the appropriate shipping method (air, sea, or ground) depending on the equipment’s size, value, and urgency. - Returns and Reverse Logistics:
Have a clear process in place for returns, repairs, and warranty claims if necessary.
Frequently Asked Questions
39
Stores In World
97
Cities With Free Shipping
300+
Five Star Rating
Our mission and vision
At Gold Health Medical, our vision is to revolutionize healthcare by providing high-quality medical equipment that enhances patient care and improves healthcare efficiency. We are committed to being a trusted partner for medical professionals and institutions, ensuring they have access to the latest and most reliable medical technology.
Our goal is to bridge the gap between innovation and accessibility, making advanced healthcare solutions available to providers worldwide. Through excellence in service, integrity, and continuous improvement, we strive to empower healthcare professionals with the tools they need to deliver superior patient outcomes.
Together, we are shaping the future of medical care—one innovation at a time.
What Our Customers Say
At Gold Health Medical, we take pride in delivering high-quality medical equipment and exceptional customer service. Here’s what our satisfied clients have to say about their experience with us:
Product Name: 1.5T MR Imaging by GoldHealth Medical
Type: Superconducting MRI System
Key Features and Benefits
- Unmatched Precision: Achieve exceptional diagnostic clarity with advanced shimming technology (Passive + Active + Dynamic) for superior imaging performance.
- Field Homogeneity: Delivers consistent and reliable results with field homogeneity as low as ≤0.015ppm at 20cm DSV, ensuring accurate imaging across various scan volumes.
- Long-Term Stability: Maintains a long-term stability of ≤0.125ppm/h, providing dependable operation over extended periods.
- Durable Construction: Crafted with high-quality materials, including acrylic and metal, ensuring robustness and longevity.
- Electric Power Source: Designed for efficient energy use, offering reliable performance in diverse medical environments.
Technical Specifications
- Instrument Classification: Class II medical device
- Safety Standards: ISO certified for safety and reliability
- Quality Certification: CE approved, meeting global healthcare standards
- Shelf Life: 2 years from production
- Field Homogeneity (V-RMS):
- 50cm DSV: ≤0.75ppm
- 45cm DSV: ≤0.37ppm
- 40cm DSV: ≤0.18ppm
- 30cm DSV: ≤0.05ppm
- 20cm DSV: ≤0.015ppm
Support and Warranty
- Comprehensive Warranty: Backed by a 2-year warranty for peace of mind.
- After-Sales Service: Access to online technical support, ensuring seamless operation and quick resolution of queries.
Logistics and Supply
- Place of Origin: China
- Port of Delivery: Guangzhou
- Supply Ability: Up to 10 sets per month, ensuring timely availability for your facility.
GoldHealth Medical’s 1.5T MR Imaging system is engineered to deliver unparalleled precision, reliability, and performance, empowering healthcare providers to achieve the best outcomes for their patients.
