MSLMRI17 Advanced 15T MRI Scanner for
GoldHealth Medical MRI System
Product Overview
GoldHealth Medical presents an advanced MRI system designed for unparalleled imaging precision and versatility. Engineered with cutting-edge technology, this system delivers exceptional performance across a wide range of medical applications, from head imaging to full-body diagnostics. Its innovative design ensures superior image quality, operational efficiency, and patient comfort.
Key Features and Technical Specifications
- Magnet System
- Magnet Type: Permanent
- Magnetic Field Strength: 0.3T ± 5%
- Magnet Appearance: C-shape for enhanced accessibility
- Weight: 12.8T ± 1.5%
- Horizontal Opening Angle: 320° for improved patient positioning
- 5-Gaussian Fringe Field: ≤ 2.5m in X, Y, Z directions, ensuring safety and minimal interference
- Shimming Methods: Passive + Active Shimming for optimal field homogeneity
-
Magnetic Field Homogeneity (VRMS, 24 points): ≤ 2.0ppm within a 40cm DSV
-
Gradient System
- Gradient Type: Ultrafast solid-state technology for rapid imaging
- Cooling Type: Air-cooled gradient amplifier and coil for reliability
- Max. Amplitude (Single Axis): 28mT/m
- Max. Slew Rate (Single Axis): 93T/m/s
-
Min. Rise Time: 0.3ms for seamless scanning
-
Resolution Parameters
- Max. Field of View (FOV): 400mm
- Min. Field of View (FOV): 10mm
- Min. 2D Slice Thickness: 1.0mm
- Min. 3D Slice Thickness: 0.1mm
- Max. Acquisition Matrix: 1024×1024
- Min. TE (Spin Echo): 5ms
- Min. TR (Spin Echo): 11ms
- Min. TE (Gradient Echo): 2ms
- Min. TR (Gradient Echo): 5ms
-
Max. b-value of DWI: 1000
-
RF System
- Type: Fully digital transmitting and receiving for superior signal clarity
- RF Amplifier Maximum Power: 6 kW
- Receiving Channels: 4 channels
- Receiving Bandwidth: 1.25 MHz
Standard Phased Array Coils
- Head Coil
- Channels: 4
- Inside Dimensions: 260mm × 211mm × 234mm (L×W×H)
- Outside Dimensions: 360mm × 340mm × 320mm (L×W×H)
- Weight: 5.1Kg
-
Applications: Head imaging, Head MR Angiography, TMJ imaging
-
Neck Coil
- Channels: 2
- Inside Dimensions: 451mm × 169mm × 192mm (L×W×H)
- Outside Dimensions: 451mm × 342mm × 312mm (L×W×H)
- Weight: 3.3Kg
-
Applications: Neck imaging, Cervical spine imaging, Neck MR Angiography
-
Body Coil (Large)
- Channels: 4
- Inside Dimensions: 323mm × 508mm × 295mm (L×W×H)
- Outside Dimensions: 323mm × 631mm × 337mm (L×W×H)
- Weight: 7.0Kg
- Applications: Thorax, spine, abdomen, pelvis, and hip imaging
Unique Selling Points
- Precision and Versatility: Advanced gradient and RF systems ensure high-resolution imaging across diverse applications.
- Patient-Centric Design: A 320° horizontal opening angle and C-shaped magnet provide comfort and accessibility.
- Safety and Reliability: Minimal fringe field and active/passive shimming guarantee a safe and consistent magnetic environment.
- Comprehensive Coil Options: Tailored coils for specific anatomical regions ensure optimal imaging outcomes.
GoldHealth Medical’s MRI system is the ideal choice for hospitals, clinics, research institutions, and rehabilitation centers seeking state-of-the-art diagnostic capabilities. With its innovative features and robust performance, it sets a new standard in medical imaging technology.
Common Shipping and Delivery Considerations
- Packaging:
Medical devices need secure packaging to avoid damage during transit, including shock-absorbing materials or custom foam inserts. - Compliance with Regulations:
Ensure compliance with local and international standards (e.g., FDA, CE) and shipping regulations like Good Distribution Practice (GDP). - Temperature Control:
Some devices require temperature-controlled shipping (e.g., refrigerated trucks or special packaging) to maintain product integrity. - Tracking and Documentation:
Shipments should be tracked with necessary documents like invoices, certificates, and import/export paperwork. - Lead Time:
Plan ahead for lead times, which can vary depending on the equipment size and delivery location. - Insurance: Due to the high value of medical equipment, consider insurance to protect against loss or damage during transit.
- Customs and Import Regulations: Account for customs procedures and tariffs when shipping internationally, ensuring proper documentation.
- Special Handling:
Fragile or hazardous medical devices may require special handling, with clear labeling to ensure proper care. - Delivery Method:
Choose the appropriate shipping method (air, sea, or ground) depending on the equipment’s size, value, and urgency. - Returns and Reverse Logistics:
Have a clear process in place for returns, repairs, and warranty claims if necessary.
Frequently Asked Questions
39
Stores In World
97
Cities With Free Shipping
300+
Five Star Rating
Our mission and vision
At Gold Health Medical, our vision is to revolutionize healthcare by providing high-quality medical equipment that enhances patient care and improves healthcare efficiency. We are committed to being a trusted partner for medical professionals and institutions, ensuring they have access to the latest and most reliable medical technology.
Our goal is to bridge the gap between innovation and accessibility, making advanced healthcare solutions available to providers worldwide. Through excellence in service, integrity, and continuous improvement, we strive to empower healthcare professionals with the tools they need to deliver superior patient outcomes.
Together, we are shaping the future of medical care—one innovation at a time.
What Our Customers Say
At Gold Health Medical, we take pride in delivering high-quality medical equipment and exceptional customer service. Here’s what our satisfied clients have to say about their experience with us:
Product Overview
GoldHealth Medical proudly presents an advanced magnetic resonance imaging solution designed to redefine precision and reliability in medical diagnostics. Engineered with cutting-edge technology, this Class II medical instrument delivers exceptional imaging performance, making it an ideal choice for hospitals, clinics, research institutions, and rehabilitation centers.
Key Features and Specifications
- Magnetic Field Strength: 1.5T ± 5%, ensuring unparalleled image clarity and diagnostic accuracy.
- Magnet Design: Innovative C-shape magnet with a horizontal opening angle of 320°, offering enhanced patient accessibility and comfort.
- 5 Gaussian Fringe Field: Controlled to ≤ 2.5m in X, Y, and Z directions, minimizing interference and ensuring safety.
- Shimming Methods: Combines Passive Shimming and Active Shimming for optimal magnetic field homogeneity.
- Max. Amplitude (Single Axis): 28mT/m, enabling high-resolution imaging of intricate anatomical structures.
- Max. Slew Rate (Single Axis): 93T/m/s, reducing scan times while maintaining image quality.
- Max. Field of View (FOV): 400mm, accommodating a wide range of clinical applications.
- RF Amplifier Maximum Power: 6 kW, supporting robust signal transmission and reception.
- Receiving Bandwidth: 1.25 MHz, ensuring precise data acquisition and minimal noise interference.
Quality and Safety
- Compliant with GB15979-2002 safety standards, guaranteeing the highest levels of operational safety.
- Certified with CE quality assurance, reflecting our commitment to global excellence.
Durability and Longevity
- Shelf Life: 2 years, ensuring extended usability and reliability.
- Constructed with premium metal materials, built to withstand demanding medical environments.
Support and Warranty
- Backed by a 1-year warranty, providing peace of mind and long-term value.
- Comprehensive online technical support, ensuring seamless operation and quick resolution of any issues.
Supply and Delivery
- Supply Capacity: 5 sets per week, ensuring timely availability for your needs.
- Ships from Guangdong, China, with standard export packaging for secure transportation.
GoldHealth Medical is dedicated to empowering healthcare professionals with innovative solutions that elevate patient care and diagnostic precision. Experience the future of medical imaging with our state-of-the-art MRI system.
