32Slice CT Scanner for Human Use
GoldHealth Medical High-Resolution CT Scanner
GoldHealth Medical introduces a state-of-the-art high-resolution CT scanner designed to revolutionize diagnostic imaging with its advanced technology and versatility. Engineered for hospitals, clinics, and research institutions, this CT scanner delivers exceptional performance, precision, and patient comfort.
Key Features
- Flexible Hardware Configurations: Two distinct hardware setups allow tailored solutions to meet diverse budgetary needs without compromising quality.
- Optimized Workflow: A robust hardware platform enhances patient throughput and boosts operational efficiency, ensuring seamless daily operations.
- Intuitive User Interface: A user-guided interface combined with auto-positioning presets simplifies procedures ranging from routine head, chest, and abdomen scans to intricate cardiac imaging.
- Superior Image Quality: Achieve unparalleled diagnostic confidence with high-resolution imaging (22lp/cm@0%MTF, 1024×1024 matrix).
- Expanded Clinical Applications: A 76cm gantry design enables tumor biopsy and simulation, broadening the scope of potential clinical applications.
Technical Specifications
Gantry
- Aperture: 70cm
- One-button positioning with 3 preset protocols
- Scan speed/360°: 0.7, 0.8, 0.9, 1.0, 1.5, 2.0s
- Scan Field of View (FOV): 43cm
- Tilt range: Digital tilt ±45° (step 0.1°)
- Auto voice support
Patient Table
- Max horizontal travel range: 1600mm
- Horizontal scannable range: 50mm~1500mm
- Horizontal travel speed: 1~200mm/s
- Vertical table travel range: 522mm~878mm
- Max table load: 206kg
- One-key patient table release and cradle switches
X-ray Tube
- Anode heat capacity: 3.5MHU (9.5MHU with iDream)
- Cooling rate: 735kHU/min
- Focal spot size: Large – 1.2mm×1.4mm, Small – 0.7mm×0.8mm
Generator
- Power rating: 42kW (113kW with iDream)
- kV settings: 70, 80, 100, 120, 140kV
- mA range: 10~350mA (1mA step)
Detector
- Material: Solid-state GOS
- Number of detector rows: 24
- Max slices/rotation: 32 (conjugated mode)
- Detector channels per row: 768
- Total detector elements: 18432
- Min slice thickness: 0.6mm
- Detector width: 19.2mm
- Max data sampling rate: 4800 views/360°
Scanning Performance
- Scout scan: Supports 3 modes (A.P., lateral, and dual); Scannable range 50~1500mm
- Acquisition modes: 32×0.6mm, 32×1.2mm, 16×0.6mm, 16×1.2mm
- Collimation width selection: 19.2mm, 9.6mm
- Pitch factor: 0.3~1.75 (multiple selections)
- Max continuous scan time: 100s
Image Reconstruction
- Reconstruction Field of View (FOV): 50~430mm (Extended: 50~600mm)
- Reconstruction matrices: 512×512, 768×768, 1024×1024
- Reconstruction speed: ≥20 ips
- Display matrix: 1024×1024
Image Optimization Algorithms
- Standard features: Metal artifact reduction, beam hardening artifact reduction, partial volume artifact reduction, streaking artifact reduction, helical scan artifact reduction, motion artifact reduction
Image Quality
- Spatial resolution: ≥16lp/cm@0%MTF (X-Y plane), ≥15lp/cm@0%MTF (Z plane)
- Low-contrast resolution: [email protected]%@25mGy
- Image noise: ≤0.35% (Central dose ≤40mGy)
- CT HU scale: Standard (-1024HU~+3072HU), Extended (-
Common Shipping and Delivery Considerations
- Packaging:
Medical devices need secure packaging to avoid damage during transit, including shock-absorbing materials or custom foam inserts. - Compliance with Regulations:
Ensure compliance with local and international standards (e.g., FDA, CE) and shipping regulations like Good Distribution Practice (GDP). - Temperature Control:
Some devices require temperature-controlled shipping (e.g., refrigerated trucks or special packaging) to maintain product integrity. - Tracking and Documentation:
Shipments should be tracked with necessary documents like invoices, certificates, and import/export paperwork. - Lead Time:
Plan ahead for lead times, which can vary depending on the equipment size and delivery location. - Insurance: Due to the high value of medical equipment, consider insurance to protect against loss or damage during transit.
- Customs and Import Regulations: Account for customs procedures and tariffs when shipping internationally, ensuring proper documentation.
- Special Handling:
Fragile or hazardous medical devices may require special handling, with clear labeling to ensure proper care. - Delivery Method:
Choose the appropriate shipping method (air, sea, or ground) depending on the equipment’s size, value, and urgency. - Returns and Reverse Logistics:
Have a clear process in place for returns, repairs, and warranty claims if necessary.
Frequently Asked Questions
39
Stores In World
97
Cities With Free Shipping
300+
Five Star Rating
Our mission and vision
At Gold Health Medical, our vision is to revolutionize healthcare by providing high-quality medical equipment that enhances patient care and improves healthcare efficiency. We are committed to being a trusted partner for medical professionals and institutions, ensuring they have access to the latest and most reliable medical technology.
Our goal is to bridge the gap between innovation and accessibility, making advanced healthcare solutions available to providers worldwide. Through excellence in service, integrity, and continuous improvement, we strive to empower healthcare professionals with the tools they need to deliver superior patient outcomes.
Together, we are shaping the future of medical care—one innovation at a time.
What Our Customers Say
At Gold Health Medical, we take pride in delivering high-quality medical equipment and exceptional customer service. Here’s what our satisfied clients have to say about their experience with us:
Product Overview
Introducing the GoldHealth Medical 32-Slice CT Scanner, a cutting-edge diagnostic solution designed to deliver unparalleled precision and efficiency. Engineered with advanced technology, this CT scanner is ideal for hospitals, clinics, research institutions, and rehabilitation centers seeking reliable, high-performance imaging equipment.
Key Features and Specifications
- Tube Capacity: Equipped with a robust 9.5MHU tube for consistent, high-quality imaging.
- Generator Power: Powered by an impressive 113kW generator, ensuring rapid and accurate scans.
- Rotation Speed: Achieves a swift 0.39-second rotation speed, minimizing patient discomfort and maximizing throughput.
- Material: Constructed from premium metal for enhanced durability and stability.
- Instrument Classification: Class I medical device, meeting rigorous industry standards.
- Power Source: Fully electric operation for seamless integration into modern healthcare facilities.
- Shelf Life: Designed for long-term reliability with a 3-year shelf life.
Quality Assurance and Certifications
- Backed by CE certification, guaranteeing compliance with international safety and quality standards.
- Supported by a comprehensive 3-year warranty, reflecting our confidence in the product's durability and performance.
After-Sales Support
- Enjoy peace of mind with free spare parts included as part of our commitment to customer satisfaction.
Packaging and Delivery
- Package Dimensions: 800 x 700 x 390 cm, ensuring secure transportation.
- Gross Weight: 800 kg, optimized for safe and efficient handling.
- Minimum Order Quantity (MOQ): Just 1 unit, offering flexibility for diverse healthcare providers.
Why Choose GoldHealth Medical?
The GoldHealth Medical 32-Slice CT Scanner combines modern design with state-of-the-art technology, empowering medical professionals to achieve exceptional diagnostic accuracy. Whether for clinical use, research, or rehabilitation, this scanner is engineered to meet the demands of today’s healthcare landscape.
Choose GoldHealth Medical for innovation, reliability, and excellence in medical imaging.
