Portable ECG Monitor 3612 Lead Handheld Device
Reference: 1601273857033
Household Medical Devices
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical ECG Machine
Product Highlights
- Intuitive 7-inch Color LCD Touch Screen: Effortlessly navigate through patient data and settings with a responsive, high-resolution display.
- Advanced ECG Analysis: Equipped with comprehensive ECG interpretation capabilities for precise diagnostics.
- Massive Patient Data Storage: Store records for over 30,000 patients, ensuring seamless data management.
- Flexible Data Export Options: Supports SD card and USB disk for convenient data transfer and backup.
Key Features
- 12-Lead Acquisition: Simultaneous acquisition of all 12 leads for accurate and efficient ECG readings.
- Robust Input Circuitry: Floating design with defibrillator protection ensures safety and reliability.
- High Input Impedance: ≥50MΩ for minimal signal distortion.
- Ultra-Low Input Circuit Current: ≤0.05μA to ensure patient safety during operation.
Recording Modes
- Automatic: Multiple configurations including 3CH×4+1R, 3CH×4, 3CHx2+2CHx3, 6CHX2.
- Manual: Flexible options such as 3CH, 2CH, 3CH+1R, 2CH+1R.
- Rhythm: Any lead can be selected for rhythm recording.
Advanced Filtering
- EMG Filter: Multiple settings (25 Hz, 30 Hz, 40 Hz, 75 Hz, 100 Hz, 150 Hz).
- DFT Filter: 0.05 Hz / 0.15 Hz.
- AC Filter: 50 Hz / 60 Hz.
- CMRR: >100dB for superior noise rejection.
Safety and Performance
- Patient Leakage Current: <10μA for enhanced safety.
- Frequency Response: 0.05Hz~150Hz (-3dB) for accurate signal capture.
- Sensitivity Options: 2.5mm/mV, 5mm/mV, 10mm/mV, 20mm/mV.
- Anti-Baseline Drift: Automatic adjustment for stable readings.
- Time Constant: ≥3.2s for reliable performance.
- Noise Level: <15μVp-p for clear and precise recordings.
Thermal Printing System
- Paper Speeds: 12.5 mm/s, 25 mm/s, 50 mm/s.
- Paper Specifications:
- Sun-7031: 80mm x 20m paper roll.
- Sun-7062: 120mm x 20m paper roll.
Power and Safety
- Power Supply: AC 100~240V, 50/60Hz, 30VA~100VA.
- Fuse: AC220V±10%, 2*Φ5×20mm, T2A/250V AC time lag.
- Safety Classification: IEC60601-1 Class I, Type CF.
Why Choose GoldHealth Medical?
GoldHealth Medical is a trusted provider of innovative medical solutions, offering superior quality products at competitive prices. Our commitment to excellence ensures timely delivery and exceptional service, making us the preferred choice for healthcare professionals worldwide.
Certifications
Our products meet rigorous international standards, ensuring reliability and safety for all users.
Frequently Asked Questions
We provide comprehensive support to address your queries and ensure a seamless experience with our products.
GoldHealth Medical – Empowering healthcare with precision and innovation.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
GoldHealth Medical presents the 3-Channel Portable ECG Machine – Precision Redefined for Modern Cardiac Care
-
Product Overview:
Elevate cardiac diagnostics with the 3-Channel Portable ECG Machine, a cutting-edge solution designed for accuracy, portability, and ease of use. Engineered to meet the demands of healthcare professionals, this device delivers exceptional performance in hospitals, clinics, research labs, and home care environments. -
Key Features and Technical Specifications:
- Input Circuit: Advanced floating design with integrated defibrillator protection circuit, ensuring safety during critical procedures.
- Input Impedance: ≥50MΩ for superior signal clarity and minimal interference.
- Common Mode Rejection Ratio (CMRR): >100dB, guaranteeing precise readings even in electrically noisy environments.
- Input Circuit Current: ≤0.05μA, ensuring patient safety and comfort during operation.
- Display: A vibrant 7" graphic LCD provides clear, detailed visualization of ECG waveforms for accurate analysis.
- Power Supply: Versatile AC input (100~240V, 50/60Hz, 30VA~100VA) with a built-in battery for uninterrupted performance during transport or in remote settings.
-
Material: Durable, high-quality plastic construction ensures longevity and portability.
-
Certifications and Compliance:
- Quality Certification: CE-certified, meeting international standards for safety and reliability.
-
Instrument Classification: Class II medical device, ensuring robust performance and patient safety.
-
Additional Details:
- Shelf Life: 1 year from the date of manufacture.
-
Place of Origin: Proudly crafted in Guangdong, China, with meticulous attention to detail and quality.
-
Why Choose GoldHealth Medical?
At GoldHealth Medical, we are committed to redefining healthcare through innovation. Our 3-Channel Portable ECG Machine combines advanced engineering with user-centric design, empowering healthcare providers to deliver exceptional patient care. With its compact form factor, reliable performance, and intuitive interface, this device is the ideal choice for modern medical environments.
Experience the future of cardiac diagnostics with GoldHealth Medical – where precision meets portability.
