GDS200 Electric Dental Unit with Doctors Chair for Clinics
Reference: 1601036158125
Dental Chair
Interested in this product?Ask about specifications, quantities and delivery.
Associated tags
No tags assigned
Product summary
GoldHealth Medical Dental Unit
Engineered for precision and comfort, the GoldHealth Medical Dental Unit is designed to elevate the patient and practitioner experience. With advanced features and meticulous attention to detail, this unit sets a new standard in dental care.
Key Features:
- Ergonomic Chair Design
- Minimum chair height: Less than 430mm
- Maximum chair height: Less than 720mm
- Load capacity: Up to 135kg (without treatment machine)
- Lifting speed: Greater than 15mm/s, ensuring smooth and stable operation
- Cushion incline: Less than or equal to 10 degrees
-
Backrest adjustment: 0 to 70 degrees for optimal positioning
-
Adjustable Headrest
- Head extension length: Less than 120mm
- Head tilt angle: 20 degrees
-
Tilt angle range: 40 degrees, offering precise patient alignment
-
Quiet and Reliable Operation
- Noise level: Less than 45 decibels
-
Equipped with a silent DC motor for safe and dependable performance
-
Intuitive Control Systems
- Dual-operation modes: Hand control and foot control for four-direction chair adjustments
- Advanced microcomputer control system with reset functionality
- Programmable logic controller (PLC) for customizable circuit control
Standard Configuration:
- 24V DC motor for chair
- Auto spittoon flushing and cup filler control system
- Inter-lock control system for enhanced safety
- Down-mounted instrument tray with air brake for convenience
- Rotatable ceramic spittoon for hygiene and ease of use
- Two 3-way syringes (hot/cold water functionality)
- Multi-function foot controller for seamless operation
- High suction and saliva ejector system for efficient procedures
- Seamless cushion (PU) for maximum comfort and durability
- Outer water tank for reliable water supply
- Built-in floor box for organized cable management
- LED sensor-operated light for precision illumination
- LED film viewer for enhanced diagnostics
- Doctor stool for practitioner comfort
Technical Specifications:
- Power voltage: 220V / 110V, 50Hz / 60Hz
- Motor voltage: 24V
- Water pressure: 0.2MPa - 0.4MPa
- Air pressure: 0.5MPa - 0.8MPa
GoldHealth Medical’s Dental Unit combines cutting-edge technology with user-centric design, ensuring unparalleled performance and reliability for modern dental practices.
Shipping & Delivery FAQ
How are products prepared before shipment?
Each item is checked against the catalog record, protected with suitable packaging materials, and prepared with available product documentation for procurement review.
Can you support international delivery requests?
The support team can coordinate delivery options by destination, product type, and documentation requirements before confirming availability.
Are fragile or calibrated products handled differently?
Sensitive products are packed with additional cushioning and handling notes; calibration or compliance documents can be reviewed during the inquiry process.
How can I estimate lead time?
Lead time depends on stock status, destination, carrier availability, and any requested documentation. Contact the product team for a product-specific estimate.
Before you choose a medical product
Practical answers about product configuration, consumables, documents, quantities and support before a medical supply inquiry.
How do I confirm the right model and configuration?
Include the product reference, intended care setting and the functions or dimensions you need. Ask which accessories are included and which are optional. Images and a shared product name may cover more than one configuration, so confirm the exact version in the supplier response.
Will accessories or consumables fit my existing equipment?
Provide the equipment manufacturer, model and the relevant connector, size or part reference. Request compatibility information for the specific combination rather than relying on visual similarity. Follow the equipment and accessory manufacturers' instructions.
Which product documents can I request?
Depending on the product, useful requests may include a specification sheet, instructions for use, packaging details or available regulatory documents. State your destination market and the exact document required. A catalog listing does not establish that every model has a particular approval or certification.
Are all consumables sterile or suitable for single use?
No assumption should be made across the catalog. Check the labeling and instructions for the exact product, including whether it is supplied sterile, its stated use, expiry information and storage requirements. Ask for clarification before purchasing if these details are missing.
Can I ask about samples, pack sizes or minimum quantities?
Yes. Tell us the item reference, the quantity you want to evaluate and the quantity expected for the project. Sample availability, pack sizes and minimum purchase quantities depend on the product and must be confirmed individually.
What should I confirm for installation and ongoing use?
For equipment, ask about power supply, installation space, setup instructions, training materials, spare parts and the applicable service or warranty terms. Confirm which support is available for the selected model and destination before agreeing to a purchase.
How are price, lead time and delivery confirmed?
Send quantities, destination and required timing with your inquiry. Request a written response covering the selected configuration, packing, commercial terms and delivery estimate. Published product information is a starting point; an inquiry is not an order confirmation.
About Gold Health
Medical supplies for the way care is delivered
Explore Gold Health: medical equipment, clinical consumables and veterinary supplies for professional procurement.
Different care settings, one place to begin
A hospital department, an independent clinic, a laboratory and a veterinary practice can have very different purchasing needs. Our catalog brings equipment, instruments and everyday supplies into a browsable starting point for these different settings.
Explore by category, inspect the product images and use the listed details to build a shortlist. Availability and the exact configuration are confirmed for the selected item when you contact the team.
Look beyond the product name
A useful product choice depends on more than a headline. Dimensions, materials, model references, accessories, packaging and instructions can all affect whether an item belongs on your purchasing list.
We encourage buyers to identify these details early and ask for the product-specific information they need before making a decision.
Equipment and consumables need different questions
For equipment, ask about the supplied configuration, compatible accessories, electrical requirements and available service information. For consumables, confirm the stated intended use, pack quantity, storage conditions and any sterile or single-use labeling for that exact item.
The catalog helps organize the conversation. Product suitability and any clinical use must be assessed using the relevant manufacturer instructions and qualified professional review.
Turn a shortlist into a useful conversation
Send the product names or references together with your quantities, destination and preferred timing. If several items form one project, explain which accessories or consumables need to work together.
This gives the team a practical basis for discussing specifications, available documents, packaging and the next commercial steps. Please keep patient information and other sensitive records out of your inquiry.
Product attributes
Product Overview
Introducing the Dental Chair Unit by GoldHealth Medical, a pinnacle of precision engineering and ergonomic design tailored for modern dental practices. This Class II medical instrument is meticulously crafted to deliver unparalleled comfort, reliability, and performance, making it an indispensable asset for dental hospitals, clinics, and treatment establishments.
Key Features and Specifications
- Application: Specifically designed for dental hospitals and treatment facilities, ensuring optimal functionality in professional environments.
- Power Source: Electric-powered for smooth, quiet, and precise operation.
- Material: Constructed from high-grade metal, ensuring durability and long-lasting use.
- Safety Standard: Compliant with GB15979-2002, guaranteeing the highest levels of safety and hygiene.
- Quality Certification: CE-certified, meeting international standards for medical equipment.
- Shelf Life: 1 year, ensuring consistent performance and reliability.
Warranty and Support
- Warranty: Comprehensive 1-year warranty for peace of mind.
- After-Sales Service: Access to online technical support, ensuring seamless assistance whenever needed.
Packaging Details
- Selling Units: Single item per unit.
- Package Dimensions: Compact at 1x1x1 cm.
- Gross Weight: Lightweight at 1.000 kg, ensuring easy handling and transportation.
Why Choose GoldHealth Medical's Dental Chair Unit?
- Ergonomic Design: Engineered for maximum patient comfort and practitioner ease.
- Advanced Engineering: Combines cutting-edge technology with robust materials for superior performance.
- Versatile Application: Ideal for a wide range of dental procedures, enhancing efficiency and precision.
Elevate your practice with GoldHealth Medical’s Dental Chair Unit – where innovation meets excellence in dental care.
