Advanced 15T MRI System for Precision Diagnostics
GoldHealth Medical: 1.5T Magnetic Resonance System
GoldHealth Medical proudly presents a cutting-edge 1.5T Magnetic Resonance Imaging (MRI) system, designed to redefine precision and usability in medical imaging. This state-of-the-art system combines advanced engineering with user-centric design, delivering exceptional performance for a wide range of clinical and research applications.
Key Features
- Innovative Design: A harmonious blend of versatility and superior optical performance ensures seamless operation and reliable results.
- Ease of Use: Intuitive controls and streamlined workflows make the system accessible to users of all experience levels.
- Advanced Imaging Capabilities: Unmatched image quality and precision for diverse diagnostic needs.
Technical Specifications
Magnet
- Field Strength: 1.5T
- Type: Superconducting
- Shimming: Passive, Active, and Dynamic shimming for optimal field stability
- Electromagnetic Interference Shielding: Equipped with advanced shielding technology
- Long-Term Stability: ≤0.125ppm/h
- Field Homogeneity (V-RMS):
- 50cm DSV: ≤0.75ppm
- 45cm DSV: ≤0.37ppm
- 40cm DSV: ≤0.18ppm
- 30cm DSV: ≤0.05ppm
- 20cm DSV: ≤0.015ppm
- 10cm DSV: ≤0.002ppm
- Patient Aperture: 600mm for enhanced patient comfort
Gradient System
- Type: Single (Non-Resonant)
- Max. Amplitude (X-, Y-, Z-Axis): 40mT/m
- Max. Slew Rate (X-, Y-, Z-Axis): 133mT/m/ms
RF Transmit and Receive
- RF Amplifier Max. Output Power: 20kW
- Independent RF Receiving Channels: 16 Channels
- RF Receiving Coils:
- MUSIC Phased Array Head-Neck Coil: 16 Channels
- MUSIC Phased Array Spine Coil: 18 Channels
- MUSIC Phased Array Body Coil: 8 Channels
- Phased Array Knee Coil: 8 Channels
- Phased Array Shoulder Coil: 4 Channels
- Optional RF Receiving Coils:
- Phased Array Wrist Coil: 8 Channels
- Phased Array Ankle Coil: 8 Channels
- Phased Array Breast Coil: 8 Channels
- Small Flexible Coil: 4 Channels
- Large Flexible Coil: 4 Channels
Pulse Sequence and Scanning Technology
- Standard Sequences: SE, GRE, EPI, IR
- Neural System Imaging: Includes Tornado (motion artifact reduction) and SWAPP
- Abdominal Imaging: Fast dynamic enhanced volumetric scanning
- DWI, MRA, MRV, Magnetic Resonance Hydrography (MRCP): Fully supported
- Precise Quantitative Techniques:
- mLIVE (Fat Liver Quantification and Iron Liver Quantification, PDFF/R2*)
- Cartilage Quantification
- Artifact Reduction and Time-Saving Technologies: Integrated for efficiency
- Optional Advanced Features:
- ASL (Arterial Spin Labeling): Includes Impulse RF Labelling and 2D ASL with post-process analysis
- MRS (Magnetic Resonance Spectroscopy): Supports STEAM/PRESS, Single Voxel MRS, and automatic high-order homogenization
GoldHealth Medical’s 1.5T MRI system is engineered to deliver unparalleled accuracy, versatility, and reliability, empowering healthcare providers to achieve superior diagnostic outcomes. Whether for hospitals, research institutions, or specialized clinics, this system sets a new benchmark in medical imaging excellence.
Common Shipping and Delivery Considerations
- Packaging:
Medical devices need secure packaging to avoid damage during transit, including shock-absorbing materials or custom foam inserts. - Compliance with Regulations:
Ensure compliance with local and international standards (e.g., FDA, CE) and shipping regulations like Good Distribution Practice (GDP). - Temperature Control:
Some devices require temperature-controlled shipping (e.g., refrigerated trucks or special packaging) to maintain product integrity. - Tracking and Documentation:
Shipments should be tracked with necessary documents like invoices, certificates, and import/export paperwork. - Lead Time:
Plan ahead for lead times, which can vary depending on the equipment size and delivery location. - Insurance: Due to the high value of medical equipment, consider insurance to protect against loss or damage during transit.
- Customs and Import Regulations: Account for customs procedures and tariffs when shipping internationally, ensuring proper documentation.
- Special Handling:
Fragile or hazardous medical devices may require special handling, with clear labeling to ensure proper care. - Delivery Method:
Choose the appropriate shipping method (air, sea, or ground) depending on the equipment’s size, value, and urgency. - Returns and Reverse Logistics:
Have a clear process in place for returns, repairs, and warranty claims if necessary.
Frequently Asked Questions
39
Stores In World
97
Cities With Free Shipping
300+
Five Star Rating
Our mission and vision
At Gold Health Medical, our vision is to revolutionize healthcare by providing high-quality medical equipment that enhances patient care and improves healthcare efficiency. We are committed to being a trusted partner for medical professionals and institutions, ensuring they have access to the latest and most reliable medical technology.
Our goal is to bridge the gap between innovation and accessibility, making advanced healthcare solutions available to providers worldwide. Through excellence in service, integrity, and continuous improvement, we strive to empower healthcare professionals with the tools they need to deliver superior patient outcomes.
Together, we are shaping the future of medical care—one innovation at a time.
What Our Customers Say
At Gold Health Medical, we take pride in delivering high-quality medical equipment and exceptional customer service. Here’s what our satisfied clients have to say about their experience with us:
Product Name: 1.5T MR Imaging by GoldHealth Medical
Type: Superconducting MRI System
Key Features and Benefits
- Unmatched Precision: Achieve exceptional imaging clarity with advanced shimming technology (Passive + Active + Dynamic) for superior diagnostic accuracy.
- Field Homogeneity: Delivers consistent imaging quality across multiple DSV ranges:
- 50cm DSV: ≤0.75ppm
- 45cm DSV: ≤0.37ppm
- 40cm DSV: ≤0.18ppm
- 30cm DSV: ≤0.05ppm
- 20cm DSV: ≤0.015ppm
- Long-Term Stability: Ensures reliable performance with a stability rate of ≤0.125ppm/h, ideal for continuous clinical and research use.
- Advanced Safety Standards: Compliant with ISO and CE certifications, ensuring the highest levels of safety and quality.
- Durable Design: Constructed with premium materials including acrylic and metal for enhanced longevity and performance.
Technical Specifications
- Instrument Classification: Class II medical device
- Power Source: Electric
- Shelf Life: 2 years
- Place of Origin: China
Support and Warranty
- Comprehensive Warranty: Backed by a 2-year warranty for peace of mind.
- Dedicated After-Sales Support: Access online technical support to ensure seamless operation and troubleshooting.
Packaging Details
- Selling Unit: Single item
- Package Dimensions: XX cm
- Gross Weight: XX kg
GoldHealth Medical’s 1.5T MR Imaging system is engineered to deliver unparalleled precision, reliability, and safety, making it the ideal choice for hospitals, clinics, research institutions, and rehabilitation centers worldwide. Elevate your diagnostic capabilities with cutting-edge technology designed to meet the demands of modern healthcare.
