15T MRI Scanner for Orthopedics Departments
GoldHealth Medical MRI System
GoldHealth Medical presents an advanced MRI system designed to deliver unparalleled precision and patient comfort. Engineered with cutting-edge technology, this MRI scanner is ideal for hospitals, clinics, research institutions, and rehabilitation centers.
Key Features and Specifications
Magnet System
- Magnet Type: Permanent Magnet with an automatic constant temperature system for consistent performance.
- Field Strength: 0.3T, ensuring high-quality imaging.
- Magnet Shape: C-shape design for enhanced accessibility.
- Homogeneity (40cm DSV, VRMS): ≤2.0ppm, providing exceptional image clarity.
- Shim Method: Active/Passive for optimal field uniformity.
- Magnet Vertical Gap (Cover): 40cm, allowing easy patient access.
- Accessibility (Horizontal Opening Angle): 320°, maximizing patient positioning flexibility.
- 5 Gauss Fringe Field:
- X-axis (horizontal): ≤2.5m
- Y-axis (vertical): ≤2.5m
- Z-axis (horizontal): ≤2.5m
Patient Couch and Communication
- Patient Couch Driven Mode: Motor-driven for smooth and precise movement.
- Max. Patient Weight: Supports up to 200kg (440lbs), accommodating a wide range of patients.
- Patient Positioning Tools: Equipped with a laser light localizer and motor-driven transfer to the center of the imaging volume for accurate positioning.
- Position Accuracy: ±1mm, ensuring precise imaging.
- Emergency Call Key: Integrated for immediate assistance.
- Intercom System: Facilitates clear communication between the operator and patient.
Gradient System
- Gradient Field Strength (Single Axis): ≥28mT/m, enabling detailed imaging.
- Gradient Slew Rate (Single Axis): ≥93mT/m/ms, ensuring rapid gradient switching.
- Rise Time: ≤0.3ms, minimizing delays in imaging.
- Gradient Cooling System: Air-cooled for reliable performance.
RF System
- RF System Type: Digital Transmit and Receive for superior signal processing.
- Number of RF Channels: 4, supporting advanced imaging techniques.
- Transmitter Amplifier Peak Power: 6kW, delivering robust signal transmission.
- RF Bandwidth of Receiver: ≥1MHz, capturing a wide range of frequencies.
- Available Coils:
- Head Coil
- Neck Coil
- Body/Spine Coil (17 inch)
- Body/Spine Coil (20 inch)
- Knee Coil
- Shoulder Coil
Computer System
- Host Computer: High-performance professional-grade system.
- System Software: Optimized for MRI operations.
- Operation Software: APEX, providing intuitive control.
- CPU Clock Rate: 3.6GHz for fast processing.
- Main Memory: 2GB, ensuring smooth operation.
- Color LCD Monitor: 19”, offering clear visualization.
- Keyboard and Mouse: Standard configuration for ease of use.
- Image Reconstruction Speed (256 x 256 Matrix): 1500 FPS, enabling rapid image generation.
- Hard Disk: 500 GB storage capacity.
- Image Storage Capacity (256 x 256 Matrix): 2,650,000 images, ensuring extensive data retention.
- Media Driver: DVD RW for convenient data transfer.
GoldHealth Medical’s MRI system combines innovative engineering with user-centric design, setting a new standard in medical imaging. Its precision, versatility, and reliability make it an indispensable tool for modern healthcare environments.
Common Shipping and Delivery Considerations
- Packaging:
Medical devices need secure packaging to avoid damage during transit, including shock-absorbing materials or custom foam inserts. - Compliance with Regulations:
Ensure compliance with local and international standards (e.g., FDA, CE) and shipping regulations like Good Distribution Practice (GDP). - Temperature Control:
Some devices require temperature-controlled shipping (e.g., refrigerated trucks or special packaging) to maintain product integrity. - Tracking and Documentation:
Shipments should be tracked with necessary documents like invoices, certificates, and import/export paperwork. - Lead Time:
Plan ahead for lead times, which can vary depending on the equipment size and delivery location. - Insurance: Due to the high value of medical equipment, consider insurance to protect against loss or damage during transit.
- Customs and Import Regulations: Account for customs procedures and tariffs when shipping internationally, ensuring proper documentation.
- Special Handling:
Fragile or hazardous medical devices may require special handling, with clear labeling to ensure proper care. - Delivery Method:
Choose the appropriate shipping method (air, sea, or ground) depending on the equipment’s size, value, and urgency. - Returns and Reverse Logistics:
Have a clear process in place for returns, repairs, and warranty claims if necessary.
Frequently Asked Questions
39
Stores In World
97
Cities With Free Shipping
300+
Five Star Rating
Our mission and vision
At Gold Health Medical, our vision is to revolutionize healthcare by providing high-quality medical equipment that enhances patient care and improves healthcare efficiency. We are committed to being a trusted partner for medical professionals and institutions, ensuring they have access to the latest and most reliable medical technology.
Our goal is to bridge the gap between innovation and accessibility, making advanced healthcare solutions available to providers worldwide. Through excellence in service, integrity, and continuous improvement, we strive to empower healthcare professionals with the tools they need to deliver superior patient outcomes.
Together, we are shaping the future of medical care—one innovation at a time.
What Our Customers Say
At Gold Health Medical, we take pride in delivering high-quality medical equipment and exceptional customer service. Here’s what our satisfied clients have to say about their experience with us:
Product Name: MRI Machine Medical by GoldHealth Medical
Key Features and Benefits:
- Advanced Magnet Technology: Equipped with a Permanent Magnet Automatic Constant Temperature System, ensuring consistent performance and reliability.
- Optimized Design: Features a C-shaped magnet with a 40cm vertical gap and a 320° horizontal opening angle for enhanced accessibility and patient comfort.
- Field Strength: Delivers a robust 0.3T magnetic field, providing clear and precise imaging for accurate diagnostics.
- Superior Homogeneity: Achieves ≤2.0ppm homogeneity within a 40cm DSV, ensuring high-quality imaging with minimal distortion.
- Shim Method: Utilizes both Active and Passive shimming techniques for optimal magnetic field precision.
Technical Specifications:
- Material: Constructed with durable steel for long-lasting performance.
- Instrument Classification: Class II medical device, designed for safety and efficiency.
- Safety Standard Compliance: Meets GB/T18830-2009 standards, ensuring the highest levels of safety and reliability.
- Power Source: Electric, engineered for consistent and stable operation.
- Shelf Life: 3 years, maintaining peak performance over time.
Certifications and Quality Assurance:
- Backed by CE and ISO certifications, guaranteeing compliance with international standards.
- Rigorous quality assurance validated by TUV certification.
Warranty and Support:
- Comprehensive Warranty: 3-year coverage for peace of mind.
- Dedicated After-Sales Service: Includes onsite training to ensure seamless integration and optimal use.
Packaging Details:
- Selling Units: Single item
- Single Package Size: XX cm
- Single Gross Weight: XX kg
Place of Origin: Proudly manufactured in Guangdong, China, combining cutting-edge innovation with precision engineering.
GoldHealth Medical’s MRI Machine is designed to meet the needs of hospitals, clinics, research institutions, and rehabilitation centers, offering unparalleled imaging quality and operational efficiency.
