GoldHealth Medical Pharmaceutical Refrigerators

GoldHealth Medical introduces a range of advanced medical refrigerators designed specifically for the cold storage of pharmaceuticals, reagents, vaccines, and biological products. These refrigerators are essential for hospitals, pharmacies, pharmaceutical factories, epidemic stations, blood banks, health centers, and laboratories.

Key Features

Precise Temperature Control System

• Advanced Control: Equipped with an Italian CAREL micro-computer control system featuring an LED screen, allowing precise temperature adjustments between 2~8℃.
• High Accuracy Sensor: Utilizes platinum resistance temperature sensors with a readability of 0.1℃ for accurate monitoring and ease of operation.

Safety Features

• Secure Access: Safety door lock and controller setting password to prevent unauthorized access.
• Comprehensive Alarm System: Visual and audible alarms for high/low temperature, power failure, sensor error, and door ajar.
• Power Failure Protection: Automatic delay in restarting the cooling system after a power outage.
• Controller Error Protection: The cooling system retains memory of normal working cycles to maintain functionality during controller or sensor failures.

Superior Refrigeration System

• German Engineering: Incorporates a Germany SECOP compressor, Germany EBM cooling fan, Germany DANFOSS dry filter, and Germany DANFOSS condensing system for reliable performance.

Humanized Design

• Customizable Storage: Adjustable shelves to accommodate various storage needs.
• Durable Construction: Features a firm glass door, inner light, and lockable design.
• Wide Voltage Range: Operates efficiently within a voltage range of 187V~242V.

Optional Features

• Backup Battery: Built-in backup battery to display temperature and power alarm system for up to 8 hours without AC power.
• LED Lighting: Auto on/off LED light with manual switch on the control panel.
• Data Recording: USB recorder for temperature data logging.
• Remote Alarm: Remote alarm system via short message.

Technical Specifications

• 50L Capacity
• Voltage: 220V/50Hz
• Power: 100W
• Temperature: 2~8℃
• Exterior Size: 470450540mm
• Weight: 40kg

• Layers: 3

• 90L Capacity

• Voltage: 220V/50Hz
• Power: 100W
• Temperature: 2~8℃
• Exterior Size: 450500820mm
• Weight: 50kg

• Layers: 3

• 130L Capacity

• Voltage: 220V/50Hz
• Power: 150W
• Temperature: 2~8℃
• Exterior Size: 5005001260mm
• Weight: 55kg

• Layers: 4

• 190L Capacity

• Voltage: 220V/50Hz
• Power: 180W
• Temperature: 2~8℃
• Exterior Size: 5305301570mm
• Weight: 60kg

• Layers: 5

• 218L Capacity

• Voltage: 220V/50Hz
• Power: 200W
• Temperature: 2~8℃
• Exterior Size: 5305301660mm
• Weight: 62kg

• Layers: 5

• 238L Capacity

• Voltage: 220V/50Hz
• Power: 220W
• Temperature: 2~8℃
• Exterior Size: 5305301680mm
• Weight: 65kg

• Layers: 5

• 260L Capacity

• Voltage: 220V/50Hz
• Power: 250W
• Temperature: 2~8℃
• Exterior Size: 5805501800mm
• Weight: 80kg

• Layers: 5

• 280L Capacity

• Voltage: 220V/50Hz
• Power: 260W
• Temperature: 2~8℃
• Exterior Size:
