GoldHealth Medical presents a cutting-edge Semi-Auto Chemistry Analyzer designed to elevate laboratory precision and efficiency.

Product Highlights

• Intuitive Interface: A vibrant 7-inch color LCD touch screen ensures effortless navigation and real-time data visualization.
• Advanced Incubation System: Equipped with 10 incubators operating at 37°C ±0.3°C, featuring 3 programmable timers for precise control.
• Versatile Testing Modes: Seamlessly switch between flow cell and cuvette testing modes, catering to diverse analytical needs.
• Energy-Saving Design: Includes a sleep mode to conserve energy during idle periods.
• Superior Connectivity: PC connectivity via RS-232 interface for seamless data transfer and enhanced workflow integration.
• Reliable Fluid Management: High-quality pump pipes imported from the United States ensure consistent performance and durability.

Technical Specifications

• Test Methods: Kinetic, Endpoint, Two-point, Absorbance.
• Absorbance Range: 0~4.500Abs with real-time curve display for accurate monitoring.
• Pre-Programmed Tests: 80 test items ready for immediate use.
• Data Storage: Memory capacity for up to 10,000 sample results.
• Wavelength Options: 7 standard filters (340nm, 405nm, 492nm, 510nm, 546nm, 578nm, 630nm) with 1 customizable position.
• Wavelength Precision: ±2nm, bandwidth ≤10nm.
• Absorbance Precision: External: 0.0001Abs, Internal: 0.00001Abs.
• Carry-Over Rate: <1% for minimal cross-contamination.
• Repeatability CV: <1% for consistent and reliable results.
• Incubator Settings: Adjustable temperatures (37°C, 30°C, 25°C) with precision of ±0.1°C.
• Sample Volume: 0~3000µL (500µL recommended).
• Quality Control: SD, CV%, and L-J quality control curves for every test item.
• Flow Cell: 32µL quartz glass with 10nm precision.
• Lamp: Long-life Philips 6V 10W halogen lamp.
• Processor: ARM series high-speed micro CPU for rapid data processing.
• Printer: Built-in thermal-sensitive printer for instant result documentation.
• Operating Environment: Temperature range 0°C~40°C, humidity up to 80%.
• Power Supply: 100~240VAC, 50-60Hz, 100VA.
• Dimensions: 340(L) x 270(W) x 160(H) mm.
• Weight: 5kg for portability and ease of placement.

Unique Advantages

• Unmatched Precision: With advanced absorbance and wavelength accuracy, this analyzer delivers unparalleled reliability for critical diagnostics.
• User-Centric Design: The intuitive touch screen and programmable settings make operation seamless for both novice and experienced users.
• Durability and Performance: High-quality components, including the imported pump pipes and long-life halogen lamp, ensure consistent performance over time.
• Comprehensive Data Management: Store up to 10,000 results and generate detailed quality control curves for every test item.

Applications

Ideal for hospitals, clinics, research laboratories, and veterinary practices, this analyzer is engineered to meet the rigorous demands of modern healthcare diagnostics.

GoldHealth Medical is committed to delivering innovative solutions that empower healthcare professionals with precision, efficiency, and reliability.
