Introducing the latest innovation from GoldHealth Medical, a cutting-edge portable EKG device designed to redefine cardiac monitoring with precision, portability, and ease of use.

Product Highlights:

• Sleek and Portable Design: Combining elegance with functionality, this device features a vibrant 7-inch color LCD screen with an 800×480 resolution for crystal-clear visualization of data.
• Advanced Signal Processing: Equipped with a high-accuracy digital filter and automatic baseline adjustment, it ensures unparalleled clarity in readings. The 12-lead synchronous acquisition and display provide comprehensive diagnostic insights.
• Intelligent Analysis: Delivers accurate pulse pace identification and robust automatic analysis, empowering healthcare professionals with reliable data interpretation.
• Versatile Recording Modes: Supports multiple recording formats including 3ch, 3ch+, 3ch+++, and 6ch, catering to diverse clinical needs. Default modes are optimized for manual (3ch) and automatic (6ch+) operations.
• Extended Battery Life: Powered by a built-in rechargeable Li-ion battery, it offers up to 4 hours of continuous operation, ensuring uninterrupted performance during critical procedures.
• High-Resolution Thermal Printing: Produces sharp, detailed outputs on 112mm x 20m thermal paper, ideal for precise documentation.
• Multilingual Support: Available in English, Chinese, French, Italian, Spanish, and Russian, making it accessible to a global audience.

Key Technical Specifications:

• Leads: Standard 12-lead configuration
• Time Constant: ≥3.2s
• Lead Acquisition: 12-bit/1000Hz (synchronous 12-lead acquisition)
• Frequency Response: 0.05–160Hz (-3dB)
• Noise Level: <15μVp-p
• Filters:
• AC Filter: 50Hz / 60Hz
• EMG Filter: 25Hz / 45Hz
• Anti-Drift Filter: 0.15Hz (adaptive)
• CMRR: ≥120dB (with AC filter)
• Sensitivity Settings: 2.5, 5, 10, 20, 40, Auto (mm/mV)
• Input Impedance: ≥50MΩ
• Paper Speed: 6.25, 12.5, 25, 50mm/s (±3%)
• Calibrating Voltage: 1mV ± 2%
• Power Supply:
• AC: 110–230V (±10%), 50/60Hz (±1Hz), 40VA
• DC: Built-in rechargeable battery, 14.4V (2000mAh)
• Dimensions/Weight: 300mm × 230mm × 75mm / 2.8kg

Unique Selling Points:

• Compact and Lightweight: Designed for portability without compromising on functionality, making it perfect for use in hospitals, clinics, laboratories, and even home care settings.
• Comprehensive Data Management: Stores and replays up to 40 patient cases, ensuring efficient record-keeping and analysis.
• Durability and Safety: Features a floating input circuit and protection against defibrillator effects, ensuring safe and reliable operation in demanding environments.

GoldHealth Medical is committed to delivering innovative solutions that empower healthcare professionals worldwide. This portable EKG device exemplifies our dedication to quality, precision, and user-centric design, setting a new standard in cardiac monitoring technology.
