Advanced 5 Color LCD AED Defibrillator
GoldHealth Medical AED: Revolutionizing Emergency Care
Product Overview
GoldHealth Medical presents an advanced Automated External Defibrillator (AED) designed for seamless operation in critical situations. Engineered with precision, this AED combines cutting-edge technology with user-centric features to ensure rapid and effective emergency response. Its compact, portable design and robust functionality make it ideal for hospitals, clinics, research labs, and even home use.
Key Features and Specifications
- Power Source: Electric
- Weight: Lightweight at just 1.5kg, including the battery
- Dimensions: Compact size of 231mm (H) x 208mm (W) x 58.5mm (D), including the integrated handle
- Durability: Withstands a 1.5-meter drop impact, ensuring reliability in demanding environments
- Portability: Comes with an integrated handle and a portable backpack for effortless transport
Environmental Resilience
- Operating Temperature: -10°C to 50°C, with the ability to function for at least 60 minutes in -20°C conditions
- Storage Temperature: -40°C to +70°C
- Protection: IP55-rated for dustproof and waterproof performance
Display and User Interface
- Screen: 5-inch color LCD display with adjustable brightness
- Guidance: Animated instructions to guide users through first aid operations
- Bilingual Support: English and Chinese interface, switchable with one click
- Voice Prompts: Adjustable volume with bilingual voice guidance
Defibrillation Performance
- Waveform Technology: Duplex wave technology, adaptable for both adults and children
- Energy Output: Maximum defibrillation energy for adults ≤150J, with a rapid 7-second charge time
- Patient Type Switching: Quick one-click toggle between adult and child modes
- Compression Modes: Adjustable settings (30:2, 15:2, continuous press) with frequencies of 100-120 compressions per minute
- Press Duration: Six adjustable durations (1, 1.5, 2, 2.5, 3, 3.4 minutes)
Electrode Design
- Integrated Electrodes: Suitable for both adults and children, with a clear schematic for proper placement
- Pre-Connection: Electrodes are pre-connected for immediate use, enhancing emergency efficiency
- Validity: 2-year shelf life with automatic self-checks and expiration alerts
Battery Performance
- Standby Life: ≥5 years at room temperature
- Shock Capacity: Supports up to 200 maximum-energy shocks under normal conditions
- Low Power Alerts: Ensures at least 30 maximum-energy shocks after a low battery warning
Data Management
- Storage: Records ECG waveforms, event data, and first aid details (e.g., analysis times, CPR duration, patient impedance)
- Transmission: Wireless data transfer to remote AED management platforms via WIFI/4G
- Export: Type-C interface for exporting rescue records to external flash memory devices
- Software: Free PC software for reviewing ECGs, defibrillation energy, and other critical data
Unique Selling Points
- Advanced Technology: Duplex wave technology ensures precise defibrillation tailored to patient impedance
- User-Friendly Design: Intuitive animations and bilingual support simplify operation for users of all skill levels
- Durability and Reliability: IP55 protection and robust drop resistance make it suitable for harsh environments
- Smart Management: Integrated AED management system for real-time monitoring and maintenance
Additional Functions
- Rescue Time Display: Tracks and displays the duration of rescue efforts
- Self-Testing: Regular self-checks ensure the device is always ready for emergencies
- Customizable Settings: Adjustable compression modes and press durations cater to diverse patient needs
GoldHealth Medical’s AED is more than a device—it’s a lifeline. Designed to empower healthcare professionals and laypersons alike, it ensures every second counts in the fight to save lives.
Common Shipping and Delivery Considerations
- Packaging:
Medical devices need secure packaging to avoid damage during transit, including shock-absorbing materials or custom foam inserts. - Compliance with Regulations:
Ensure compliance with local and international standards (e.g., FDA, CE) and shipping regulations like Good Distribution Practice (GDP). - Temperature Control:
Some devices require temperature-controlled shipping (e.g., refrigerated trucks or special packaging) to maintain product integrity. - Tracking and Documentation:
Shipments should be tracked with necessary documents like invoices, certificates, and import/export paperwork. - Lead Time:
Plan ahead for lead times, which can vary depending on the equipment size and delivery location. - Insurance: Due to the high value of medical equipment, consider insurance to protect against loss or damage during transit.
- Customs and Import Regulations: Account for customs procedures and tariffs when shipping internationally, ensuring proper documentation.
- Special Handling:
Fragile or hazardous medical devices may require special handling, with clear labeling to ensure proper care. - Delivery Method:
Choose the appropriate shipping method (air, sea, or ground) depending on the equipment’s size, value, and urgency. - Returns and Reverse Logistics:
Have a clear process in place for returns, repairs, and warranty claims if necessary.
Frequently Asked Questions
39
Stores In World
97
Cities With Free Shipping
300+
Five Star Rating
Our mission and vision
At Gold Health Medical, our vision is to revolutionize healthcare by providing high-quality medical equipment that enhances patient care and improves healthcare efficiency. We are committed to being a trusted partner for medical professionals and institutions, ensuring they have access to the latest and most reliable medical technology.
Our goal is to bridge the gap between innovation and accessibility, making advanced healthcare solutions available to providers worldwide. Through excellence in service, integrity, and continuous improvement, we strive to empower healthcare professionals with the tools they need to deliver superior patient outcomes.
Together, we are shaping the future of medical care—one innovation at a time.
What Our Customers Say
At Gold Health Medical, we take pride in delivering high-quality medical equipment and exceptional customer service. Here’s what our satisfied clients have to say about their experience with us:
Product Name: AED by GoldHealth Medical
Key Features:
- Compact and Lightweight Design: Weighs just 1.5kg, including the battery, making it highly portable for use in any setting.
- Integrated Handle & Portable Backpack: Designed for effortless transport and rapid deployment in emergencies.
- Durability You Can Trust: Withstands a 1.5-meter drop impact, ensuring reliability in demanding environments.
- Advanced Protection: IP55-rated for dustproof and waterproof performance, capable of withstanding extreme conditions from -40°C to +70°C.
- Bilingual Support: English and Chinese interfaces with one-click switching for seamless communication.
Technical Specifications:
- Dimensions (Including Handle): 231 mm (H) x 208 mm (W) x 58.5 mm (D)
- Power Source: Electric
- Shelf Life: 2 years
- Instrument Classification: Class III medical device
- Quality Certification: CCC
Unique Selling Points:
- Unmatched Portability: Perfect for hospitals, clinics, ambulances, and even home use, ensuring lifesaving technology is always within reach.
- Extreme Environment Resilience: Engineered to perform reliably in harsh conditions, from scorching heat to freezing cold.
- User-Friendly Interface: Intuitive bilingual operation ensures ease of use for diverse users, reducing response time during critical moments.
Warranty & Support:
- Comprehensive Warranty: 1-year coverage for peace of mind.
- Dedicated After-Sales Service: Online technical support available to assist with any queries or troubleshooting needs.
Applications:
Ideal for hospitals, clinics, research labs, rehabilitation centers, and emergency response teams. Its portability and durability also make it a reliable choice for home users and remote locations.
Minimum Order Quantity (MOQ): 1 unit
GoldHealth Medical’s AED is more than a device—it’s a lifeline designed to empower healthcare professionals and save lives with confidence and precision.
